NT-EC1100-HP

The NT-EC1100-HP is a high-performance EtherCAT fieldbus adapter for flexible remote I/O systems. Key Features: Supports EtherCAT real-time protocol • Freely mix digital, analog, and special function modules • Expandable up to 32 slice modules ($32 \times 32$ digital I/O) • Upgraded 2.0A internal power supply for high-density setups.

Send Email Inquiry Now

Introduction

NT-EC1100-HP: High-Performance EtherCAT Remote I/O Network Adapter

NT-EC1100-HP Technical Specifications
Bus & Communication Parameters
Bus Protocol	EtherCAT Protocol (DC, Ring Topology, Freerun)
Station Address Setting	Master Assigned / Software Configuration
Cable Requirement	Category 5 Shielded Twisted-Pair (CAT5 STP)
Transmission Distance & Speed	100 m (Station-to-Station) @ 100 Mbps Full Duplex
Max Data Buffer	1024 Bytes Input / 1024 Bytes Output
Power Specifications
EX System-Side Power Input	24V DC (18V ~ 36V DC)
EX System-Side Supply Current	2.0 A (Max.) @ 5V DC
Field I/O Power Input	24V DC (±20%)
Field I/O Output Current	10 A (Max.)
Technical & Diagnostic Features
Expansion Capacity	Up to 32 Slice I/O Modules (Max 32×32 Digital Points)
Diagnostic & Monitoring	Internal Temperature & System Power Supply Voltage Monitoring, Address Mapping
